MOD-NRF24LR
RF 2.4GHz transciever module with NRF24L01
| Price | 3.95 EUR |
|---|---|
| 10 - 49 pcs | 3.75 EUR |
| 50 - 10000 pcs | 3.56 EUR |
FEATURES
- NRF24L01 2.4GHz low power transciever
- UEXT to connect to host microcontroller (standard connector on our ARM development boards)
- SPI 0-8Mhz interface
- 125 RF channels
- up to 2Mbit data rate
- 1.8-3.6V operating voltage
- PCB: FR-4, 1.5 mm (0,062"), red soldermask, white silkscreen component print
- Dimensions: MOD-NRF24LR - 34x18 mm (1.34x0.7"); MOD-NRF24LS - 51x18 mm (2.0 x 0.7")
DOCUMENTS
HARDWARE
SOFTWARE
- LPC-P2148 demo code for bi-directional communication with MOD-NRF24L
