iMX233-OLinuXino-MICRO
Open Source Hardware Embedded ARM Linux Single board computer with i.MX233 ARM926J @454Mhz
This item is OBSOLETE
iMX233-OLinuXino-Micro is OSHW certified Open Source Hardware with UID BG000049.
iMX233-OLinuXino-Micro is a single-board Linux computer in a very compact form
FEATURES
- iMX233 ARM926J processor at 454Mhz
- 64 MB RAM
- SD-card connector for booting the Linux image
- TV PAL/NTSC video output
- 1 USB High Speed Host
- Three buttons
- 2x30 pin GPIO for connection of other hardware
- PCB dimensions: 3.00'' x 1.70'' (76.2mm x 43.2mm)
- Nominal dimensions: 3.40'' x 1.70'' (86.4mm x 43.2mm)
DOCUMENTS
HARDWARE
SOFTWARE
- GitHub OLINUXINO Project
- Open Embedded Linux Kernel with TV-console and peripherial support, instructions how to make bootable SD-card here
- How to Build Debian distribution instructions here and how to make a bootable SD-card with Debian rootfs here
- How to Build ARCH Linux distribution instructions here
- How to build Linux Kernel with LTIB (obsolete) here
- Open Embedded layer completed with support for iMX233-OLinuXino
- Linux Kernel 3.X support work in progress
- Android build on iMX233 instructions (in Spanish)
- OpenOCD working script for iMX233 - tested with OpenOCD 0.6.0, ARM-USB-TINY-H and iMX233-SJTAG
- BitBurner software - software used for burning the iMX233 fuses
- Emulation of OLinuXino
- Image links, instructions, demo software, customer projects and more might be found at the wiki page: iMX233 article
COMMUNITY
- OLinuXino forum for discussion and community support
