AgonLight2-Proto - Open Source Hardware Board

AgonLight2-Proto Prototype board for AgonLight2

https://www.olimex.com/Products/Retro-Computers/AgonLight2-Proto/open-source-hardware

Price	4.00 EUR

AgonLight2-Proto is OSHW certified Open Source Hardware with UID BG0000109

AgonLight2-Proto is a small extension DIY kit compatbile with AgonLight2. It allows you to fast prototype concept and ideas with AgonLight2 computer.

Notice that the LEDs, resistors, IDC connector are not soldered. When soldering the LEDs, make sure to also solder the resistors!

FEATURES

Female-IDC connector 34 pin for connection tp AgonLight2's GPIO header
3mm RED LED for 5V power indication
3mm GREEN LED for 3.3V power indication
2 x 2k PTH resistors for the LEDs
Sea-of-pads spaced at 2.54mm
GND and 3.3V bus connecting vertically all pads on the left edge
GND and 5V bus connecting vertically all pads on the right edge
Dimensions: (100x80) mm
3 x distance spacers for keeping the board horizontal when ICD connector is attached to AgonLight2's GPIO
